Space Steel Truss Bridge 3000mm*1400mm Modular Steel Bridges

Space Steel Truss Bridge/space Steel Frame Truss Bridge

Jiangsu Zhonghai Bridge Equipment Co., Ltd.'s quality control process is in the leading position in the industry, in line with international standards, and even exceeds the industry average in some aspects.

In line with industry standards
- **ISO 9001:2000 certification**: The company has successfully passed the ISO 9001:2000 international quality system certification. This certification is a widely recognized quality management standard internationally, requiring companies to establish a strict quality management system to ensure the quality of products and services. Passing this certification shows that the company has met international standards in quality control and can provide customers with products and services that meet international standards.
- **Ultrasonic flaw detection**: The company conducts ultrasonic flaw detection on all major welds to ensure that the quality of the welds meets the welding standards. This detection method is a relatively strict detection method in the industry, which can effectively detect potential defects in welds and ensure the safety and reliability of bridge structures.
- **SGS testing**: In order to meet the needs of the international market, the company's exported steel products are all tested by SGS to ensure that they fully comply with American and European standards. SGS is an internationally recognized inspection, identification, testing and certification organization with strict inspection standards. Products that pass SGS inspection have higher recognition in the international market.

Beyond the industry average
- **Automatic welding robot technology**: The company is the first domestic enterprise to achieve fully automatic welding of Bailey bridges. By introducing automatic welding robot technology, the company not only improves production efficiency, but also significantly reduces human errors, so that the welding accuracy is controlled within 0.3 mm. This high-precision welding technology is at the leading level in the industry, ensuring the stability and consistency of product quality.
- **Strict quality supervision and inspection**: All products of the company are strictly supervised and regularly inspected by the scientific research station of the General Armament Department to ensure that each product meets strict quality standards. This strict quality supervision mechanism is relatively rare in the industry and reflects the company's high attention to product quality.
- **Continuous technological innovation**: The company continues to accelerate the company's scientific and technological innovation capabilities, focusing on corporate technology research and development, production processes and product detail optimization. Through technological innovation, the company has not only improved product quality, but also improved production efficiency, further consolidating its position in the industry.

Summary
Jiangsu Zhonghai Bridge Equipment Co., Ltd. has passed strict ISO 9001:2000 quality management system certification, ultrasonic flaw detection, SGS testing and other measures to ensure that product quality meets international standards. At the same time, the company has introduced automatic welding robot technology, strict supervision and inspection mechanisms and continuous technological innovation, making its quality control leading in the industry, even surpassing the industry average in some aspects.

Specifications:

​

CB200 Truss Press Limited Table
NO.	Internal Force	Structure Form
		Not Reinforced Model				Reinforced Model
		SS	DS	TS	QS	SSR	DSR	TSR	QSR
200	Standard Truss Moment(kN.m)	1034.3	2027.2	2978.8	3930.3	2165.4	4244.2	6236.4	8228.6
200	Standard Truss Shear (kN)	222.1	435.3	639.6	843.9	222.1	435.3	639.6	843.9
201	High Bending Truss Moment(kN.m)	1593.2	3122.8	4585.5	6054.3	3335.8	6538.2	9607.1	12676.1
202	High Bending Truss Shear(kN)	348	696	1044	1392	348	696	1044	1392
203	Shear Force of Super High Shear Truss(kN)	509.8	999.2	1468.2	1937.2	509.8	999.2	1468.2	1937.2

​​

CB200 Table of Geometric Characteristics of Truss Bridge(Half Bridge)
Structure	Geometric Characteristics
	Geometric Characteristics	Chord Area(cm2)	Section Properties(cm3)	Moment of Inertia(cm4)
ss	SS	25.48	5437	580174
	SSR	50.96	10875	1160348
DS	DS	50.96	10875	1160348
	DSR1	76.44	16312	1740522
	DSR2	101.92	21750	2320696
TS	TS	76.44	16312	1740522
	TSR2	127.4	27185	2900870
	TSR3	152.88	32625	3481044
QS	QS	101.92	21750	2320696
	QSR3	178.36	38059	4061218
	QSR4	203.84	43500	4641392

​​

CB321(100) Truss Press Limited Table
No.	Lnternal Force	Structure Form
		Not Reinforced Model				Reinforced Model
		SS	DS	TS	DDR	SSR	DSR	TSR	DDR
321(100)	Standard Truss Moment(kN.m)	788.2	1576.4	2246.4	3265.4	1687.5	3375	4809.4	6750
321(100)	Standard Truss Shear (kN)	245.2	490.5	698.9	490.5	245.2	490.5	698.9	490.5
321 (100) Table of geometric characteristics of truss bridge(Half bridge)
Type No.	Geometric Characteristics	Structure Form
		Not Reinforced Model				Reinforced Model
		SS	DS	TS	DDR	SSR	DSR	TSR	DDR
321(100)	Section properties(cm3)	3578.5	7157.1	10735.6	14817.9	7699.1	15398.3	23097.4	30641.7
321(100)	Moment of inertia(cm4)	250497.2	500994.4	751491.6	2148588.8	577434.4	1154868.8	1732303.2	4596255.2

​

Advantage

Possessing the features of simple structure,
convenient transport, speedy erection
easy disassembling,
heavy loading capacity,
great stability and long fatigue life
being capable of an alternative span, loading capacity

Introduction to Jiangsu Zhonghai Bridge Equipment Co., Ltd.
Jiangsu Zhonghai Bridge Equipment Co., Ltd., established in 2010, is a high-tech enterprise specializing in the research, development, manufacturing, and sales of bridge equipment. With a registered capital of 55 million yuan, the company boasts a modern production base and advanced manufacturing facilities, achieving an annual output exceeding 60,000 tons. Its products are widely used in major bridge projects and transportation infrastructure construction both domestically and internationally.
The company consistently prioritizes technological innovation, supported by a skilled R&D team and long-term collaborations with renowned universities and research institutions. By continuously adopting and assimilating international advanced technologies, the company has achieved remarkable results in the fields of bridge steel structures, bridge construction equipment, and bridge inspection equipment. Multiple products have obtained national patent certifications and have been awarded provincial and municipal science and technology progress prizes.
In terms of production management, the company strictly adheres to the ISO9001 quality management system to ensure stable and reliable product quality. With exquisite craftsmanship and a rigorous approach, the company’s products have earned an excellent reputation in the market, serving clients across the country and exporting to regions such as Southeast Asia, the Middle East, and Africa.
Jiangsu Zhonghai Bridge Equipment Co., Ltd. adheres to the business philosophy of “Quality First, Service Excellence,” committed to providing high-quality products and comprehensive services to its clients. Looking ahead, the company will continue to increase investment in R&D, enhance its core competitiveness, and contribute to the development of China’s bridge construction industry, striving to become a global leader in the bridge equipment sector.
