M19 Waterproof Solder Wire Connectors 16 Pin IP67 Wire To Wire
Connector
Product Overview
M19 IP67 Wire Connectors Male To Female Industrial Connector
featuring a 16-pin configuration with IP67 protection level.
Designed specifically for wire-to-wire connections, these
connectors ensure firm soldered connections with low contact
impedance for stable power and signal transmission. Excellent
waterproof, dustproof, and vibration-resistant performance makes
them ideal for complex working conditions.
Construction & Applications
Manufactured from weather-resistant engineering materials with
precision sealing structure, these connectors effectively resist
rain, dust, and moisture. Suitable for outdoor, humid, and dusty
environments. Widely used in industrial control, security
monitoring, outdoor electronic equipment, and new energy auxiliary
devices, providing long-term reliable wire-to-wire connections.
Main Features
- Push lock quick release system
- Multicore options: 2Pin, 3Pin, 4Pin, 5Pin for Power
- 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin for power signal
combined
- 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin
for signal available
- Field assembly version: both wire to wire and wire to board options
- Current rated 5A for long time working
- Cable assembly service supported, welcome to custom
- OEM/ODM welcome
Application Industries
- Growth Lights
- Communications Application
- Product coding machines
- Inventory product coding
- Inkjet systems
- Solar System
- Industrial inkjet equipment
- Electric power equipment
- Laboratory forensic & pathology equipment
- Communications equipment
- Heavy machinery
Electrical Parameters
| Number of Poles | 16Pin |
| Current Rating | 5A max. |
| Voltage Rating | 300VAC max |
| Durability Voltage | 1500VAC @ 60 s. |
Technical Parameters
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) when mated |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
Operation Parameters
| Voltage Rating | 300VAC max |
| Current Rating | 5A max |
| Min Wire Size OD | 3.0mm ~ 6.0mm |
| Max Wire Size OD | 8.0mm ~ 10.0mm |
| Max. Cable Cross Section Area | 0.5mm² ~ 2.5mm² |
Design Sketch
Frequently Asked Questions
Q: Are you a factory or trading company?
A: We are a factory. Located in Ulinkcon Industrial Park, Bao'an
District, Shenzhen, China
Q: What shipping methods do you offer? How long is the delivery
time?
A: We provide multiple shipping options: 1) Courier
(DHL/UPS/FedEx): 3 - 7 working days for small parcels; 2) Air
freight: 7 - 15 working days; 3) Sea freight: 20 - 45 working days.
Delivery time varies by destination and shipping method.
Q: Can I have custom label?
A: Yes, of course, you can make your own private label and package.
If you need to design the packaging, we also have professional
designer to serve you.
