| Name: | SJFC-200 Dust Concentration Measuring Instrument PM2.5 Detector |
| Outside Dim: | 200×160×90(Wide×High×Deep) |
| Display: | 3.5 inch color screen(optional) |
| Weight: | 2.5KG |
| Size channels: | PM1.0 PM2.5 PM10 (or PM2.5 PM10 TSP) |
| Detection Range: | 0-40mg/m3 |
| Company Info. |
| Suzhou Sujing Automation Equipment corporation limited |
| Verified Supplier |
| View Contact Details |
| Product List |
SJFC-200 Dust Concentration Measuring Instrument PM2.5 Detector
This SJFC-200 Dust Concentration Measuring Instrument PM2.5 Detector adopts the advanced microcomputer technology, which is processed by the central processing unit, which has the advantages of fast processing speed, strong anti-interference ability and high measurement accuracy.
The specification of dust particle measurement
| Outside Dim | 200×160×90(Wide×High×Deep) |
| Display | 3.5 inch color screen(optional) |
| Battery | built-in 5200mah li-ion Battery(optional) |
| Weight | 2.5kg |
| Max.Consumption | 10W |
| Power Source | DC12-24V |
| Size channels | PM1.0 PM2.5 PM10 (or PM2.5 PM10 TSP) |
| Flow Rate | 1L/min ±5% flow (long life pump) |
| Sample Time | 1-999s Selectable, ≥6s recommended |
| Sensibility | 0.1µg/m3 |
| Repeatability | ≤±2% |
| Accuracy | ≤±10% |
| Detection Range | 0-40mg/m3 |
| Data Output | RS485 / RS232 |
| Comm. protocol | Modbus RTU |
| Operating Time | 5 hours |
| Optional parameters | Temperature, RH, combustible gas, oxygen, carbon dioxide, etc. |
| Data records | 2000 |
| Environmental | Temperature: -10-50℃; Humidity:<85%RH; Atmosphere Pressure:86-106Kpa |
| Accessories | Carrying case, power adapter, zero count filter , Optional: explosion protective and outdoor protective case |
The picture of dust particle measurement
