| Categories | Fiber Optic Patch Cord |
|---|---|
| Brand Name: | Huayixin |
| Model Number: | Fiber patch cord |
| Certification: | CE/ISO9001 |
| Place of Origin: | China |
| MOQ: | 100 pcs |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1000000 pcs per |
| Delivery Time: | 5-8 working days after payment |
| Packaging Details: | stander packing |
| Fiber type: | Simplex and Duplex, G652D, G655, anything, SM or MM |
| Application: | FTTH FTTB FTTX Network |
| Connector type: | PC/UPC/APC, SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO, ST SC LC FC, SC/Apc & SC/Upc, SC-SC LC-LC FC-FC ST-ST or Hybrid |
| Length: | 1m 2m 3m or Customized |
| Insertion loss: | ≤0.3dB, < 0.2dB, <=3.0 dB |
| Connector: | LC, SC, SC LC FC ST MU, anything, SC/APC |
| Material: | PVC, LSZH, PVC/LSZH |
| Product name: | Fiber Optic Patch Cord |
| Return loss: | >55dB, >30dB, >=35 dB, 50dB, ≥45dB |
| Color: | Yellow, Orange or others |
| Wavelength: | 850 nm, 1310nm, 1310nm or 1550nm |
| Fiber count: | Simplex or Duplex, Duplex |
| Quality control: | 100% test before shipping |
| Polish: | APC, UPC, PC, PC/UPC/APC |
| Real factory: | Yes |
| OEM: | Accpet |
Product Description
A ptachcords can be split into three crucial components, the connector, the cable and the manufacturing process. These three areas all contribute to the performance of a patch cord, but above all the manufacturing process is the one that defines the performance of the assembly. The range of high performance SC, FC, ST, LC, MTRJ, MU, fiber optic cables come in any combination, including angled (angle polished) SCA, MUA, FCA, STA, LCA, MPO Angled. We offer a range of Flammability options, PVC and LSZH. Features include, low insertion loss and outstanding return loss performance. All cables are available in 1.8mm or 2.8mm duplex and 4.8mm round.
1:Precise connector
2:Customized length
3:Excellent mechanical capability
4:Insertion loss<0.2dB,
5:Good durability and exchangeability
6:Compliant with Telcordia GR-326-CORE, TIA/EIA and IEC standard
Features:
Low insertion loss High return loss
Excellent mechanical endurance
High credibility and stability
Good in repeatability and exchangeability
| Fiber type | Min. Bandwidth | Distance | attenuation |
| 62.5/125 | 850/1300nm 200/500 MHz/Km | @100Mbps 2km @1Gig 220m | 850/1300nm 3.0/1.0dB/km |
| 50/125 | 850/1300nm 500/500 MHz/Km | @100Mbps 2km @1Gig 500m | 850/1300nm 3.0/1.0dB/km |
50/125 10Gig Optimized | 850/1300nm 2000/500 MHz/Km | @100Gig Varies by VCSEL typical 300m 2850nm | 850/1300nm 3.0/1.0dB/km |
| 9/125 | 1310/1550nm Approx 100 Terahertz | Up to 100km Varies by transceiver | 1310/1550nm 0.4/0.3dB/km |
Ordering Information
Boot (cable size) | Boot Color | Fiber Type | Cable number | Ferrule | Length |
0.9mm 2.0mm 3.0mm | Black Beige Blue Gray White Yellow | 9/125um SM 50/125um MM 62.5/125um MM OM3 OM4 | Simplex Duplex Multi-fiber | UPC APC | Customized |
| Parameter | Single Mode | Multi Mode | |||
| Basic | Fiber connector | FC, SC, LC, ST, MU, MTRJ, MPO | |||
| Ferrule End-face | PC | UPC | APC | UPC | |
| Insertion Loss | ≤0.2dB | ≤0.2dB | ≤0.3dB | ≤0.3bB | |
| Return Loss | ≥50dB | ≥55dB | ≥60dB | ≥35dB | |
| Ceramic Ferrule Specification | 125.5um concentricity deviations:<=1um | 127um concentricity deviations:<=3um | |||
| Suitable Fiber | 9/125um | 50/125um,62.5/125um | |||
| End-face Geometry | Radius of Curvature | 7~25mm | 5~12mm | N/A | |
| Fiber Protrusion | ≤50nm | ≤100nm | N/A | ||
| Fiber Under Cut | ≤100nm | ≤100nm | N/A | ||
| Apex offset | ≤50um | ||||
| Mechanical | Exchangeability | ≤0.2dB | |||
| Salt Spray | ≤0.1dB | ||||
| Drop | ≤0.2dB(1.5M, 5 drops) | ||||
| Vibration | IL ≤0.2dB(550Hz, 1.5mm) | ||||
| Repeatability | ≤ 0.1dB(1000 times) | ||||
| Durability | > 1000 times | ||||
| Operating Temperature | -40°C ~ +85°C | ||||
|
