| Categories | Powder Grinder Machine |
|---|---|
| Brand Name: | Brightsail |
| Model Number: | BSP |
| Certification: | CE ISO |
| Place of Origin: | China |
| MOQ: | one set |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20 sets per month |
| Delivery Time: | 30-35 days |
| Packaging Details: | Container |
| Product name: | Herb pulverizer spice grinder machine |
| Work voltage: | customized |
| Material: | SS304/316L |
| Model: | 250,350,450,500,750 |
| Input size: | <15mm |
| Fineness: | 60-2500 mesh |
| Application: | food, pharmacy, chemical, etc |
| Usage: | grinding |
| Function: | make powder |
| Company Info. |
| Jiangyin Brightsail Machinery Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Herb pulverizer spice grinder machine
Product description:
This machine is composed of three parts: main grinding part, cyclone, dust collector, blower and electronic control box. It is compact in design, reasonable in structure, and has air-selected type, no screen and no net. The machine is equipped with grading mechanism, which can make the crushing and grading complete at one time.
Features:
1) Simple structure ,easy in installation and maintenance.
2) Adopting quality brand motor, electric parts, bearing and
operation parts.
3) No dust during production, and dust can be collected in dust
collecting box.
Advantages:
1) The powder production process is continuous because the grinder has crusher part, cyclone, dust collector, etc.
2) The output powder can be very fine and the powder size distribution is very even because of the grading wheels used in the mill chamber.
3) No need screen or sieve in mill chamber, change powder particle size by changing speed through inverter.
Application:
Technical data:
| Model | BSP-350 | BSP-450 | BSP-500 | BSP-750 |
| Input size(mm) | <15 | <15 | <15 | <15 |
| Fineness(mesh) | 60-2500 | 60-2500 | 60-2500 | 60-2500 |
| Capacity(kg/h) | 20-200 | 40-500 | 60-800 | 120-1800 |
| Crush motor(kw) | 11 | 18.5 | 30 | 55 |
| Grade motot(kw) | 1.5 | 4 | 5.5 | 11 |
| Blower(kw) | 7.5 | 11 | 18.5 | 37 |
| Feed motor(kw) | 0.55 | 0.55 | 0.75 | 1.5 |
| Discharge motor(kw) | 0.75 | 0.75 | 1.1 | 1.5 |
| Speed of principle axia(rpm) | -6500 | -5350 | -4600 | -3100 |
| Grading impeller speed(rpm) | 4000 | 4000 | 3500 | 3000 |
| Weight(kg) | 1600 | 1800 | 2300 | 3100 |
Customer's visit:
If you are interested in such device, please let me know the following details:
1)What is your raw material
2)What capacity you need? Kg/hr
3)What powder particle size you need? (like 40 mesh, 60 mesh, 100mesh,200mesh....etc)
|
