Ground Hole Drilling Machine / Horizontal Directional Drilling Rig Earth Auger KR50A 1200mm

​​

​​

Type	KR50A
Excavator Size	14t-16t	20t-23t	24t+
Max. torque	50 kN.m	50 kN.m	50 kN.m
Max. drilling diamete	1200 mm	1200 mm	1200 mm
Max. drilling depth	16 m	20 m	24 m
Max. cylinder thrust	70 kN	75 kN	75 kN
Max. cylinder trip	1100 mm	1100 mm	1100 mm
Main winch pull force	65 kN	65 kN	65 kN
Main winch speed	48 m/min	48 m/min	48 m/min
Mast inclination(Lateral)	±6°	±6°	±6°
Mast inclination(Forward)	-30°~ +90°	-30°~ +90°	-30°~ +90°
Working speed	7-40rpm	7-40rpm	7-40rpm
Min. radius of gyration	2800mm	2950mm	5360mm
Max. pilot pressure	31.5Mpa	31.5Mpa	31.5Mpa
Operating height	8868mm	9926mm	11421mm
Operating width	2600mm	2800mm	3300mm
Transport height	2731mm	3150mm	3311mm
Transport width	2600mm	2800mm	3300mm
Transport length	10390mm	11492mm	12825mm
Transport weight	6.1t	6.5t	7t
Remark	Restructuring big arm	Restructuring big arm	Original arm

​

​

​

​






FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
How to Contact Us?
Send your Inquiry Details in the Below, Click "Send" Now!

TYSIM PILING EQUIPMENT CO., LTD is a leading enterprise specialized in the R&D and manufacturing of small and medium sized compact rotary drilling rigs. TYSIM is also a member of the management committee of the Association of the National Foundation Industry within the Association of the National Construction Machinery Industry. TYSIM, a National high-tech enterprise, has passed ISO9001 quality management system certification and JiangSu Province privately owned high-tech enterprise certification. The whole series of products have passed CE certification. It has registered more than 40 patents designs.

TYSIM includes small sized rotary drilling rigs, modular drilling rigs, Caterpillar chassis series medium sized rotary drilling rigs, hydraulic pile breakers, and other related products. The small rotary drilling rigs of TYSIM KR series and KP series of hydraulic pile breakers are now one of the professional brands in the piling industry. Four years in a row, TYSIM was recognized by the China Road Machinery Net as the top ten brands to receive users attention. In 2019, it was rated as one of the top 50 professional manufacturers of construction machinery by China construction machinery industry association.

After close to 10 years of focusing on rotary drilling rigs, TYSIM has developed a full range of small and medium sized rotary drilling rigs comprising the KR series:  KR50, KR80, KR90, KR125, KR150, KR220C, KR285C,KR300,KR360; the M series multi-functional drilling rigs KR80M, 90M, KR125M, KR220M with long auger CFA Function, and the low height KR125ES and KR300ES rotary drilling rigs.

TYSIM drilling rigs is not only suitable for various civil urbanization construction projects, but also suitable for subway, viaduct and redevelopment of old estate projects. Featuring high efficiency and reliable performance, the KR series of small drilling rigs have gained excellent recognitions in both at home and abroad. TYSIM 's products have been exported in batches to Australia, Singapore, Russia, Thailand, Argentina, Vietnam, Indonesia, Philippines, Qatar, Zambia and more than 40 countries. In tandem with the advancement of the Chinese construction industry to the next higher level, TYSIM drilling rigs will become the optimal machinery for the urbanization infrastructure and redevelopmrnt constructions.

The KP series of hydraulic pile breakers (also known as concrete pile cutter) originated by TYSIM have solved the pile cutting issues in the most effective way. It has enabled rapidly cutting of piles in a much shorter time which has changed the traditional manual cutting method in China. TYSIM KP series of hydraulic pile breakers have won 11 core patents, including one patent for invention in China. At present, TYSIM pile breakers have been exported to America, England, Brazil, Australia, Vietnam, Indonesia, Sri Lanka and other 40 countries.

.

Under the leadership of the founder Mr. Xin (Peng), a committee member of the National Foundation Construction Machinery Committee within the National Standardization Committee, TYSIM has put in place a team of dedicated professionals with solid experience specialized in pilling industry. They have built a cohesive team with broad international vision and rich product experience. Adhering to the core concept of “Value Creation Focus” and instilling the principle of “focusing on details and continuous improvement”, to devote to the R&D and manufacturing of the small and medium sized rotary drilling rigs, TYSIM has upheld and further strengthened its leading position in technical expertise and market shares to promote the upgrading of drilling equipment of the domestic foundation industry. In time to come, TYSIM will become a top tier brand name in the domestic market as well as the international market.
