Rugged IP66 WiFi 4W Mesh Radio AES Encryption LAN HDMI Low Latency Video Transmitter

The ZKManet2252UM is a robust MESH radio with an IP66 rating, featuring integrated 4G, GPS/BD, PTT, and 2.4G WiFi capabilities. It supports HDMI and LAN inputs and includes an LCD digital display that provides real-time device status updates. The device is equipped with a convenient buckle-up battery for easy replacement. It can be utilized in various applications, including as a manpack radio, a fixed-point relay, or mounted on mobile platforms such as vehicles, robots, or unmanned ships.

* Supports 4G-LTE network

* Supports LAN and HDMI inputs

* Supports 2.4G MIMO WiFi and GPS/BD

* Supports voice intercom

* Data rate up to 82Mbps

* With LCD to show device parameters in real time

* Optional buttons for parameters configuration

* Full duplex transparent IP data transmission

* Rugged IP66 housing

Front View

1- Battery butterfly clasp

2- Power input port for main body

3- Configuration buttons for frequency, bandwidth and distance

4- Digital LCD indicator

5- HDMI input interface

6- Power push button

7- LAN interface (RJ45)

8- MESH antenna interface-2

9- WIFI antenna interface

10- MESH signal LED indicator

11-4G antenna interface

12-PTT Mic interface

13-GPS/BD antenna interface

14- MESH antenna interface-1

Rear View

1- Battery indicator

2- Mounting hole

Inner View

1- Battery +/- contact pins

2- SIM card slot

Topology Diagram

* Star Type

* Mesh Type

* Random Type

Application Scenario
